Graphics card XFX Radeon RX Vega 64 Black Fan, specifications and benchmarks

This section outlines the key features of the graphics card XFX Radeon RX Vega 64 Black Fan.

• Based on
  AMD RX Vega 64
• GPU Chip
  Vega 10 XT
• Execution units
  64
• Shader
  4096
• Render Output Units
  64
• Texture Units
  256

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Memory Size
  8 GB
• Memory Type
  HBM2
• Memory Speed
  0.945 GHz
• Memory Bandwith
  484 GB/s
• Memory Interface
  2048 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. XFX Radeon RX Vega 64 Black Fan.

• Base Clock
  1.247 GHz
• Boost Clock
  1.546 GHz
• Overclocking
  Yes

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  295 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. XFX Radeon RX Vega 64 Black Fan.

• Fan-Type
  Radial
• Cooler-Type
  Air cooling
• Fan 1
  1 x 70 mm
• Noise (Idle)
  --
• Fan 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Displays
  4
• HDCP-Version
  --
• HDMI Ports
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. resolution
  7680x4320
• DirectX
  12_1
• Raytracing
  No
• DLSS / FSR
  No
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  No

• Length
  280 mm
• Height
  127 mm
• Width
  40 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q3/2017
• Release price
  --
• Structure size
  14 nm
• Part-no
  RX-VEGMTBFX6
• Documents
  --

Common positions XFX Radeon RX Vega 64 Black Fan GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1014 place
• Battlefield 5
  1374 place
• Shadow of the Tomb Raider
  1935 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  921 place
• Crypto-Mining Ergo Hashrate (MH/s)
  174 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1075 place
• 3DMark Benchmark
  1969 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  633 place
