Tarjeta gráfica ASRock Radeon RX 5700 8G, especificaciones y puntos de referencia

This section outlines the key features of the graphics card ASRock Radeon RX 5700 8G.

• Basado en
  AMD Radeon RX 5700
• Chip GPU
  Navi 10
• Unidades de ejecución
  36
• Shader
  2304
• Unidades de salida de renderizado
  64
• Unidades de textura
  144

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Tamaño de la memoria
  8 GB
• Tipo de memoria
  GDDR6
• Velocidad de la memoria
  1.75 GHz
• Banda de memoria con
  448 GB/s
• Interfaz de memoria
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASRock Radeon RX 5700 8G.

• Frecuencia base
  1.465 GHz
• Frecuencia máxima
  1.725 GHz
• Avg (Game) Clock
  1.625 GHz
• Overclocking
  Sí

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  180 W
• TDP (up)
  220 W
• Tjunction max
  --
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASRock Radeon RX 5700 8G.

• Tipo de ventilador
  Radial
• Tipo de refrigerador
  Air cooling
• Ventilador 1
  1 x 80 mm
• Noise (Idle)
  0 dB / Silent
• Ventilador 2
  --
• Noise (Load)
  46-47 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Muestra
  4
• Versión HDCP
  2.3
• Puertos HDMI
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4
• Puertos DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Resolución máxima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sí
• DLSS / FSR
  No
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  No

• Longitud
  281 mm
• Altura
  127 mm
• Width
  42 mm
• Anchura (ranuras)
  2 PCIe-Slots
• Weight
  --

• Interfaz de la GPU
  PCIe 4.0 x 16
• Fecha de publicación
  Q3/2019
• Release price
  329 $
• proceso tecnológico
  7 nm
• Parte-no
  90-GA16ZZ-00UANF
• especificación
  data sheet

Posiciones comunes ASRock Radeon RX 5700 8G GPU en benchmarks populares, para comparar con otros modelos.

• FP32 Performance (Single-precision TFLOPS)
  1779 place
• Battlefield 5
  1716 place
• Shadow of the Tomb Raider
  1709 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  747 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1118 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1951 place
• 3DMark Benchmark
  1817 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  671 place
