Tarjeta gráfica ASUS Dual GeForce RTX 3060 V2 OC Edition LHR, especificaciones y puntos de referencia

This section outlines the key features of the graphics card ASUS Dual GeForce RTX 3060 V2 OC Edition LHR.

• Basado en
  NVIDIA GeForce RTX 3060 LHR
• Chip GPU
  GA106-302-A1
• Unidades de ejecución
  28
• Shader
  3584
• Unidades de salida de renderizado
  64
• Unidades de textura
  112

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Tamaño de la memoria
  12 GB
• Tipo de memoria
  GDDR6
• Velocidad de la memoria
  1.875 GHz
• Banda de memoria con
  360 GB/s
• Interfaz de memoria
  192 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS Dual GeForce RTX 3060 V2 OC Edition LHR.

• Frecuencia base
  1.320 GHz
• Frecuencia máxima
  1.867 GHz+ 5 %
• Avg (Game) Clock
  1.837 GHz
• Overclocking
  Sí

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  170 W
• TDP (up)
  170 W
• Tjunction max
  --
• PCIe-Power
  1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS Dual GeForce RTX 3060 V2 OC Edition LHR.

• Tipo de ventilador
  Axial
• Tipo de refrigerador
  Air cooling
• Ventilador 1
  2 x 100 mm
• Noise (Idle)
  0 dB / Silent
• Ventilador 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Muestra
  4
• Versión HDCP
  2.3
• Puertos HDMI
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• Puertos DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Resolución máxima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sí
• DLSS / FSR
  Sí
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Longitud
  200 mm
• Altura
  123 mm
• Width
  38 mm
• Anchura (ranuras)
  2 PCIe-Slots
• Weight
  --

• Interfaz de la GPU
  PCIe 4.0 x 16
• Fecha de publicación
  Q2/2021
• Release price
  459 $
• proceso tecnológico
  8 nm
• Parte-no
  DUAL-RTX3060-O12G-V2
• especificación
  data sheet

Posiciones comunes ASUS Dual GeForce RTX 3060 V2 OC Edition LHR GPU en benchmarks populares, para comparar con otros modelos.

• FP32 Performance (Single-precision TFLOPS)
  905 place
• Battlefield 5
  1314 place
• Shadow of the Tomb Raider
  1079 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1836 place
• Crypto-Mining Ergo Hashrate (MH/s)
  869 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1335 place
• 3DMark Benchmark
  1489 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  2097 place
