Tarjeta gráfica GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR, especificaciones y puntos de referencia

This section outlines the key features of the graphics card GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR.

• Basado en
  NVIDIA GeForce RTX 3070 LHR
• Chip GPU
  GA104-302-A1
• Unidades de ejecución
  46
• Shader
  5888
• Unidades de salida de renderizado
  96
• Unidades de textura
  184

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Tamaño de la memoria
  8 GB
• Tipo de memoria
  GDDR6
• Velocidad de la memoria
  1.75 GHz
• Banda de memoria con
  448 GB/s
• Interfaz de memoria
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR.

• Frecuencia base
  1.500 GHz
• Frecuencia máxima
  1.770 GHz+ 3 %
• Overclocking
  Sí

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  240 W+ 9 %
• TDP (up)
  250 W+ 4 %
• Tjunction max
  93 °C
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR.

• Tipo de ventilador
  Axial
• Tipo de refrigerador
  Air cooling
• Ventilador 1
  3 x 80 mm
• Noise (Idle)
  0 dB / Silent
• Ventilador 2
  --
• Noise (Load)
  42-43 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Muestra
  4
• Versión HDCP
  2.3
• Puertos HDMI
  2x HDMI v2.1
• DP Ports
  2x DP v1.4a
• Puertos DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Resolución máxima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sí
• DLSS / FSR
  Sí
• LED
  GIGABYTE RGB Fusion

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Longitud
  282 mm
• Altura
  115 mm
• Width
  41 mm
• Anchura (ranuras)
  2 PCIe-Slots
• Weight
  --

• Interfaz de la GPU
  PCIe 4.0 x 16
• Fecha de publicación
  Q2/2021
• Release price
  679 $
• proceso tecnológico
  8 nm
• Parte-no
  GV-N3070EAGLE OC-8GD
• especificación
  data sheet

Posiciones comunes GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR GPU en benchmarks populares, para comparar con otros modelos.

• FP32 Performance (Single-precision TFLOPS)
  505 place
• Battlefield 5
  591 place
• Shadow of the Tomb Raider
  678 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1010 place
• Crypto-Mining Ergo Hashrate (MH/s)
  426 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  652 place
• 3DMark Benchmark
  615 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1121 place
