Tarjeta gráfica KFA2 GeForce RTX 2080 EX OC, especificaciones y puntos de referencia

This section outlines the key features of the graphics card KFA2 GeForce RTX 2080 EX OC.

• Basado en
  NVIDIA GeForce RTX 2080
• Chip GPU
  TU104
• Unidades de ejecución
  46
• Shader
  2944
• Unidades de salida de renderizado
  64
• Unidades de textura
  184

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Tamaño de la memoria
  8 GB
• Tipo de memoria
  GDDR6
• Velocidad de la memoria
  1.75 GHz
• Banda de memoria con
  448 GB/s
• Interfaz de memoria
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. KFA2 GeForce RTX 2080 EX OC.

• Frecuencia base
  1.515 GHz
• Frecuencia máxima
  1.845 GHz+ 8 %
• Avg (Game) Clock
  1.710 GHz
• Overclocking
  Sí

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  215 W
• TDP (up)
  --
• Tjunction max
  89 °C
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. KFA2 GeForce RTX 2080 EX OC.

• Tipo de ventilador
  Axial
• Tipo de refrigerador
  Air cooling
• Ventilador 1
  2 x 100 mm
• Noise (Idle)
  --
• Ventilador 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Muestra
  4
• Versión HDCP
  2.2
• Puertos HDMI
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4a
• Puertos DVI
  --
• VGA Ports
  --
• USB-C Ports
  1

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Resolución máxima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sí
• DLSS / FSR
  Sí
• LED
  Addressable LED

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Longitud
  295 mm
• Altura
  143 mm
• Width
  52 mm
• Anchura (ranuras)
  3 PCIe-Slots
• Weight
  --

• Interfaz de la GPU
  PCIe 3.0 x 16
• Fecha de publicación
  Q3/2018
• Release price
  --
• proceso tecnológico
  12 nm
• Parte-no
  28NSL6UCU9OK
• especificación
  data sheet

Posiciones comunes KFA2 GeForce RTX 2080 EX OC GPU en benchmarks populares, para comparar con otros modelos.

• FP32 Performance (Single-precision TFLOPS)
  1261 place
• Battlefield 5
  1121 place
• Shadow of the Tomb Raider
  978 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1120 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1625 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  687 place
• 3DMark Benchmark
  999 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  832 place
