Scheda grafica ASUS ROG Strix GeForce RTX 3060 Ti OC, specifiche e parametri di riferimento

This section outlines the key features of the graphics card ASUS ROG Strix GeForce RTX 3060 Ti OC.

• Basato su
  NVIDIA GeForce RTX 3060 Ti
• Chip GPU
  GA104-200-A1
• Unità di esecuzione
  38
• Shader
  4864
• Unità di uscita del rendering
  80
• Unità di texture
  152

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Dimensione della memoria
  8 GB
• Tipo di memoria
  GDDR6
• Velocità della memoria
  1.75 GHz
• Banda di memoria
  448 GB/s
• Interfaccia di memoria
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS ROG Strix GeForce RTX 3060 Ti OC.

• Frequenza di base
  1.410 GHz
• Frequenza massima
  1.890 GHz-3 %
• Avg (Game) Clock
  1.860 GHz+ 12 %
• Overclock
  Sì

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  240 W+ 20 %
• TDP (up)
  325 W+ 48 %
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS ROG Strix GeForce RTX 3060 Ti OC.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Ventilatore 1
  3 x 95 mm
• Noise (Idle)
  0 dB / Silent
• Ventilatore 2
  --
• Noise (Load)
  35-36 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Visualizzazioni
  4
• Versione HDCP
  2.3
• Porte HDMI
  2x HDMI v2.1
• DP Ports
  3x DP v1.4a
• Porte DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Risoluzione massima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sì
• DLSS / FSR
  Sì
• LED
  ASUS Aura Sync

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Lunghezza
  319 mm
• Altezza
  140 mm
• Width
  58 mm
• Larghezza (slot)
  3 PCIe-Slots
• Weight
  --

• Interfaccia GPU
  PCIe 4.0 x 16
• Data di rilascio
  Q4/2020
• Release price
  499 $
• Processo tecnologico
  8 nm
• Part-no
  ROG-STRIX-RTX3060TI-O8G-GAMING
• Specifica
  data sheet

Posizioni comuni ASUS ROG Strix GeForce RTX 3060 Ti OC GPU in benchmark popolari, per un confronto con altri modelli.

• FP32 Performance (Single-precision TFLOPS)
  598 place
• Battlefield 5
  752 place
• Shadow of the Tomb Raider
  738 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  376 place
• Crypto-Mining Ergo Hashrate (MH/s)
  644 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1101 place
• 3DMark Benchmark
  720 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  232 place
