Scheda grafica GIGABYTE Radeon RX 6950 XT GAMING OC 16G, specifiche e parametri di riferimento

This section outlines the key features of the graphics card GIGABYTE Radeon RX 6950 XT GAMING OC 16G.

• Basato su
  AMD Radeon RX 6950 XT
• Chip GPU
  Navi 21 KXTX (RDNA 2)
• Unità di esecuzione
  80
• Shader
  5120
• Unità di uscita del rendering
  128
• Unità di texture
  320
• Raytracing Cores
  80

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Dimensione della memoria
  16 GB
• Tipo di memoria
  GDDR6
• Memory Clock
  2.250 GHz
• Velocità della memoria
  18 Gbps
• Banda di memoria
  576 GB/s
• Interfaccia di memoria
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. GIGABYTE Radeon RX 6950 XT GAMING OC 16G.

• Frequenza di base
  1.925 GHz
• Frequenza massima
  2.324 GHz
• Avg (Game) Clock
  2.116 GHz
• Overclock
  Sì

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  335 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  3 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. GIGABYTE Radeon RX 6950 XT GAMING OC 16G.

• Fan-Type
  Axial
• Ventilatore 1
  3 x 100 mm
• Ventilatore 2
  --
• Cooler-Type
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Visualizzazioni
  4
• Versione HDCP
  2.3
• Porte HDMI
  2x HDMI v2.1
• DP Ports
  2x DP v1.4a
• Porte DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Risoluzione massima
  7680x4320
• DirectX
  12_2 (Ultimate)
• Raytracing
  Sì
• DLSS / FSR
  Sì
• LED
  GIGABYTE RGB Fusion

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP8
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  Decode

• Lunghezza
  332 mm
• Altezza
  143 mm
• Width
  57 mm
• Larghezza (slot)
  3 PCIe-Slots
• Weight
  --

• Interfaccia GPU
  PCIe 4.0 x 16
• Data di rilascio
  Q2/2022
• Release price
  --
• Processo tecnologico
  7 nm
• Part-no
  GV-R695XTGAMING OC-16GD
• Specifica
  data sheet

Posizioni comuni GIGABYTE Radeon RX 6950 XT GAMING OC 16G GPU in benchmark popolari, per un confronto con altri modelli.

• FP32 Performance (Single-precision TFLOPS)
  350 place
• Battlefield 5
  31 place
• Shadow of the Tomb Raider
  197 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  708 place
• Crypto-Mining Ergo Hashrate (MH/s)
  861 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  911 place
• 3DMark Benchmark
  34 place
• Cyberpunk 2077
  20 place
• GTA 5 Benchmark (Grand Theft Auto V)
  23 place
