Karta graficzna GALAX GeForce GTX 1060 EXOC 6GB, specyfikacje i wzorce

This section outlines the key features of the graphics card GALAX GeForce GTX 1060 EXOC 6GB.

• Na podstawie
  NVIDIA GeForce GTX 1060 6GB
• Układ GPU
  GP106-410-A1
• Jednostki wykonawcze
  10
• Shader
  1280
• Jednostki wyjściowe renderingu
  48
• Jednostki tekstury
  80

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Rozmiar pamięci
  6 GB
• Typ pamięci
  GDDR5
• Szybkość pamięci
  2.002 GHz
• Pasmo pamięci
  192 GB/s
• Interfejs pamięci
  192 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. GALAX GeForce GTX 1060 EXOC 6GB.

• Częstotliwość podstawowa
  1.544 GHz+ 3 %
• Maksymalna częstotliwość
  1.759 GHz+ 3 %
• Overclocking
  Tak

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  120 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  1 x 6-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. GALAX GeForce GTX 1060 EXOC 6GB.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Wentylator 1
  2 x 90 mm
• Noise (Idle)
  --
• Wentylator 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Wyświetlacze
  4
• HDCP-Version
  2.2
• Porty HDMI
  1x HDMI v2.0b
• DP Ports
  1x DP v1.4
• Porty DVI
  2
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Maks. rozdzielczość
  7680x4320
• DirectX
  12_1
• Raytracing
  Nie
• DLSS / FSR
  Nie
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Nie
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Nie

• Długość
  268 mm
• Wysokość
  139 mm
• Width
  42 mm
• Szerokość (szczeliny)
  2 PCIe-Slots
• Weight
  --

• Interfejs GPU
  PCIe 3.0 x 16
• Data wydania
  Q3/2016
• Release price
  --
• Proces technologiczny
  16 nm
• Część nr
  60NRH7DVM6EC
• specyfikacja
  data sheet

Wspólne stanowiska GALAX GeForce GTX 1060 EXOC 6GB GPU w popularnych benchmarkach, dla porównania z innymi modelami.

• FP32 Performance (Single-precision TFLOPS)
  2625 place
• Battlefield 5
  2614 place
• Shadow of the Tomb Raider
  2926 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  2587 place
• Crypto-Mining Ergo Hashrate (MH/s)
  2508 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  2600 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  1995 place
