Karta graficzna XFX Speedster QICK 319 Radeon RX 6700 XT BLACK Gaming, specyfikacje i wzorce

This section outlines the key features of the graphics card XFX Speedster QICK 319 Radeon RX 6700 XT BLACK Gaming.

• Na podstawie
  AMD Radeon RX 6700 XT
• Układ GPU
  Navi 22 XT
• Jednostki wykonawcze
  40
• Shader
  2560
• Jednostki wyjściowe renderingu
  64
• Jednostki tekstury
  160

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Rozmiar pamięci
  12 GB
• Typ pamięci
  GDDR6
• Szybkość pamięci
  2 GHz
• Pasmo pamięci
  384 GB/s
• Interfejs pamięci
  192 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. XFX Speedster QICK 319 Radeon RX 6700 XT BLACK Gaming.

• Częstotliwość podstawowa
  2.457 GHz+ 6 %
• Maksymalna częstotliwość
  2.622 GHz+ 2 %
• Avg (Game) Clock
  2.548 GHz+ 5 %
• Overclocking
  Tak

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  230 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. XFX Speedster QICK 319 Radeon RX 6700 XT BLACK Gaming.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Wentylator 1
  1 x 100 mm
• Noise (Idle)
  0 dB / Silent
• Wentylator 2
  2 x 90 mm
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Wyświetlacze
  4
• HDCP-Version
  2.3
• Porty HDMI
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• Porty DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Maks. rozdzielczość
  7680x4320
• DirectX
  12_2
• Raytracing
  Tak
• DLSS / FSR
  Nie
• LED
  Addressable LED

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode / Encode
• AV1
  Decode

• Długość
  323 mm
• Wysokość
  132 mm
• Width
  51 mm
• Szerokość (szczeliny)
  3 PCIe-Slots
• Weight
  --

• Interfejs GPU
  PCIe 4.0 x 16
• Data wydania
  Q2/2021
• Release price
  --
• Proces technologiczny
  7 nm
• Część nr
  RX-67XTYPBDP
• specyfikacja
  data sheet

Wspólne stanowiska XFX Speedster QICK 319 Radeon RX 6700 XT BLACK Gaming GPU w popularnych benchmarkach, dla porównania z innymi modelami.

• FP32 Performance (Single-precision TFLOPS)
  887 place
• Battlefield 5
  739 place
• Shadow of the Tomb Raider
  757 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  947 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1154 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  977 place
• 3DMark Benchmark
  810 place
