Cartão gráfico MSI GeForce RTX 2080 Ti Duke 11G OC, especificações e padrões de referência

This section outlines the key features of the graphics card MSI GeForce RTX 2080 Ti Duke 11G OC.

• Com base em
  NVIDIA GeForce RTX 2080 Ti
• Chip GPU
  TU102
• Unidades de execução
  68
• Shader
  4352
• Unidades de saída de renderização
  88
• Unidades de Textura
  272

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Tamanho da memória
  11 GB
• Tipo de memória
  GDDR6
• Скорость памяти
  1.75 GHz
• Banda de memória com
  616 GB/s
• Interface de memória
  352 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. MSI GeForce RTX 2080 Ti Duke 11G OC.

• Frequência de base
  1.350 GHz
• Frequência máxima
  1.665 GHz+ 8 %
• Avg (Game) Clock
  1.545 GHz
• Overclocking
  Sim

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  260 W+ 4 %
• TDP (up)
  320 W
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. MSI GeForce RTX 2080 Ti Duke 11G OC.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Ventilador 1
  3 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Ventilador 2
  --
• Noise (Load)
  42 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Máx. Ecrãs
  4
• HDCP-Version
  2.2
• HDMI Ports
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  1

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Resolução máxima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sim
• DLSS / FSR
  Sim
• LED
  MSI Mystic Light

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Não

• Comprimento
  314 mm
• Altura
  120 mm
• Width
  50 mm
• Largura (Slots)
  3 PCIe-Slots
• Weight
  1233 g

• Interface GPU
  PCIe 3.0 x 16
• Data de lançamento
  Q3/2018
• Release price
  1,579 $
• Processo tecnológico
  12 nm
• Part-no
  --
• Documentos
  data sheet

Posições comuns MSI GeForce RTX 2080 Ti Duke 11G OC GPU em referências populares, para comparação com outros modelos.

• FP32 Performance (Single-precision TFLOPS)
  786 place
• Battlefield 5
  523 place
• Shadow of the Tomb Raider
  509 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  548 place
• Crypto-Mining Ergo Hashrate (MH/s)
  793 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  353 place
• 3DMark Benchmark
  499 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  421 place
