图形卡 Colorful GeForce RTX 3080 Ti NB EX-V, 规格和基准

This section outlines the key features of the graphics card Colorful GeForce RTX 3080 Ti NB EX-V.

• 基于
  NVIDIA GeForce RTX 3080 Ti
• GPU芯片
  GA102-225-A1 (Ampere)
• Streaming Multiprocessors
  80
• 着色器
  10240
• 渲染输出单位
  112
• 纹理单位
  320
• Raytracing Cores
  80

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• 内存大小
  12 GB
• 存储器类型
  GDDR6X
• Memory Clock
  1.188 GHz
• 内存速度
  19 Gbps
• Memory bandwidth
  912 GB/s
• 存储器接口
  384 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. Colorful GeForce RTX 3080 Ti NB EX-V.

• 基准频率
  1.365 GHz
• 最大频率
  1.665 GHz
• Avg (Game) Clock
  --
• 超频
  是

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  350 W
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. Colorful GeForce RTX 3080 Ti NB EX-V.

• 风扇类型
  Axial
• 风扇1
  3 x 90 mm
• 风扇2
  --
• 冷却器类型
  Air cooling
• Noise (Idle)
  0 dB / Silent
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• 最大。显示
  4
• HDCP-版本
  2.3
• HDMI端口
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI端口
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• 最大分辨率
  7680x4320
• DirectX
  12_2 (Ultimate)
• 光线追踪
  是
• DLSS / FSR
  是
• LED
  No LED lighting

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• h265 / HEVC
  Decode / Encode
• VP8
  Decode
• VP9
  Decode
• AV1
  Decode

• 长度
  317 mm
• 高度
  135 mm
• Width
  60 mm
• 宽度（槽位）
  3 PCIe-Slots
• Weight
  1400 g

• GPU接口
  PCIe 4.0 x 16
• 发布日期
  Q4/2021
• Launch Price
  1,199 $ (Reference)
• 技术过程
  8 nm
• 数
  --
• 规格
  data sheet

共同立场 Colorful GeForce RTX 3080 Ti NB EX-V 在流行的基准测试中的GPU，用于与其他模型进行比较.

• Battlefield 5
  219 place
• Shadow of the Tomb Raider
  46 place
• Cyberpunk 2077
  16 place
• GTA 5 Benchmark (Grand Theft Auto V)
  28 place
