Grafikkarte ASUS TUF Gaming GeForce RTX 3070 OC, Spezifikationen und Benchmarks

This section outlines the key features of the graphics card ASUS TUF Gaming GeForce RTX 3070 OC.

• Based on
  NVIDIA GeForce RTX 3070
• GPU Chip
  GA104-300-A1
• Ausführungseinheiten
  46
• Shader
  5888
• Render Output Einheiten
  96
• Textur Einheiten
  184

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Speichergröße
  8 GB
• Speicher Typ
  GDDR6
• Speicher Geschwindigkeit
  1.75 GHz
• Speicherbandbreite mit
  448 GB/s
• Speicherschnittstelle
  256 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. ASUS TUF Gaming GeForce RTX 3070 OC.

• Grundfrequenz
  1.500 GHz
• Maximale Frequenz
  1.845 GHz+ 7 %
• Avg (Game) Clock
  1.815 GHz
• Übertaktung
  Ja

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  220 W
• TDP (up)
  250 W+ 4 %
• Tjunction max
  93 °C
• PCIe-Power
  2 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. ASUS TUF Gaming GeForce RTX 3070 OC.

• Ventilator-Typ
  Axial
• Kühler-Typ
  Air cooling
• Fan 1
  3 x 95 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  44-45 dB

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Anzeigen
  4
• HDCP-Version
  2.3
• HDMI-Ports
  2x HDMI v2.1
• DP Ports
  3x DP v1.4a
• DVI-Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Max. Auflösung
  7680x4320
• DirectX
  12_2
• Raytracing
  Ja
• DLSS / FSR
  Ja
• LED
  ASUS Aura Sync

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Länge
  300 mm
• Höhe
  127 mm
• Width
  52 mm
• Breite (Schlitze)
  3 PCIe-Slots
• Weight
  --

• GPU Schnittstelle
  PCIe 4.0 x 16
• Datum der Veröffentlichung
  Q4/2020
• Release price
  759 $
• Technologischer Prozess
  8 nm
• Teil-Nr
  TUF-RTX3070-O8G-GAMING
• Spezifikation
  data sheet

Gemeinsame Standpunkte ASUS TUF Gaming GeForce RTX 3070 OC GPU in gängigen Benchmarks, zum Vergleich mit anderen Modellen.

• FP32 Performance (Single-precision TFLOPS)
  429 place
• Battlefield 5
  489 place
• Shadow of the Tomb Raider
  599 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  408 place
• Crypto-Mining Ergo Hashrate (MH/s)
  335 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  533 place
• 3DMark Benchmark
  536 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  161 place
